UNS S39274 is a highly alloyed super duplex stainless steel grade developed to deliver exceptional mechanical strength and corrosion resistance in demanding industrial environments. Known for its dual-phase microstructure (ferrite-austenite), this material outperforms many conventional stainless steels in terms of toughness, stress resistance, and longevity under extreme conditions. For industries where mechanical reliability is critical such as offshore drilling, chemical processing, and desalination, understanding the mechanical properties of UNS S39274 is key to selecting the right material.
UNS S39274 is classified as a super duplex stainless steel, with a high level of chromium (25–27%), molybdenum (3.5–4.5%), and nitrogen. Its ferrite-austenite structure contributes to improved mechanical strength and greater resistance to pitting, crevice corrosion, and stress corrosion cracking, especially in chloride-rich or acidic environments.
This grade is commonly specified in ASTM standards such as ASTM A182 and ASTM A479 for forged or rolled fittings, flanges, bars, and pressure vessel components.
Below is a table of the typical mechanical property values associated with UNS S39274:
| Element | Percentage (%) |
|---|---|
| Chromium | 25.0 – 27.0 |
| Nickel | 6.0 – 8.0 |
| Molybdenum | 3.5 – 4.5 |
| Nitrogen | 0.3 max |
| Carbon | 0.03 max |
| Manganese | 1.0 max |
| Silicon | 0.8 max |
| Iron | Balance |
These values make UNS S39274 suitable for high-load and high-pressure environments where standard stainless steel may fail or degrade over time.
1. High Yield and Tensile Strength:
UNS S39274 provides nearly double the yield strength of common austenitic stainless steels like 316L. This means thinner sections of material can be used while still maintaining structural integrity, which can lower weight and cost in applications such as offshore equipment and subsea systems, leading to a strong infrastructure.
2. Superior Impact Resistance:
The alloy maintains high impact strength at sub-zero temperatures, making it suitable for cryogenic and arctic environments especially in liquefied natural gas (LNG) systems and marine operations.
3. High Hardness Without Brittleness:
Despite its higher hardness (up to 290 HB), UNS S39274 retains excellent ductility and formability, enabling fabrication processes like machining, welding, and forging without risking material failure.
Due to these properties, UNS S39274 is ideal for:
Each of these applications demands a balance between corrosion resistance and mechanical strength, a requirement that super duplex stainless steel grades like UNS S39274 meet efficiently.
| Grade | Tensile Strength (MPa) | PREN (Corrosion Resistance) | Best Used For |
|---|---|---|---|
| 2205 Duplex | 620 | 35–38 | General chemical processing |
| S32760 | 750 | 41–43 | Offshore and marine |
| S39274 | 750+ | >42 | Critical pressure systems |
When sourcing UNS S39274, it’s essential to choose experienced super duplex stainless steel suppliers who provide:
